High-Tensile Safety Spring Locking Pin for Bauer P/N 259681
API-Grade Aftermarket Safety Spring Locking Pin Compatible with Bauer P/N 259680 Main Connection Pins on BG Series Rotary Drilling Rigs
Disclaimer: All manufacturer names, symbols, part numbers (including Bauer, BG 20H, BG 28, BG 36, P/N 259681, PN 259681, and P/N 259680), and descriptions are referenced strictly for cross-reference, technical identification, and mechanical compatibility purposes. Our products are independent, high-grade aftermarket replacement safety components and are neither manufactured nor endorsed by the OEM.
Prevent Downhole Tool Detachment and Catastrophic NPT
During rotary drilling operations, rock auger coring, and high-speed soil spinning, the joint connecting the Kelly bar drive box to the drilling tool endures intense rotational shocks and continuous dynamic vibration. If a safety locking pin (OEM Part Number: 259681 / P/N 259681 / MPN 259681) suffers spring fatigue or sheared retaining tabs, the primary connection pin (P/N 259680) can migrate out of position, causing downhole tool detachment.
Fishing a dropped drilling bucket or core barrel from a deep borehole creates catastrophic Non-Productive Time (NPT) and severe financial loss. Sourcing original components through conventional dealer networks often entails 6-to-12-week lead times and steep unit markups.
Our precision-manufactured Safety Spring Locking Pin (Cross-Reference Part Number: 259681 / PN 259681-EQ) delivers high elasticity, superior corrosion resistance in heavy bentonite slurry, and 100% mechanical compatibility with OEM main connection pins at a 35–45% procurement cost reduction. Explore our comprehensive catalog of foundation drilling rig replacement parts.
Technical Specifications & Paired Pin Assembly Reference
| Engineering Parameter | OEM Specification | Aftermarket Replacement Standard | Compliance & Tolerance |
|---|---|---|---|
| OEM Cross-Reference P/N | 259681 / PN 259681 | PN-259681-EQ | 100% Direct Fit |
| Paired Main Joint Pin | Bauer P/N 259680 | Compatible with P/N 259680 | Zero Play Fitment |
| Applicable Rigs | Bauer BG Series (BG 15H – BG 40) | Standard Foundation Kelly Boxes | Direct Drop-in Fit |
| Spring Clip Material | Alloy Spring Steel | 60Si2Mn / 50CrV4 High-Elasticity Alloy | Tensile: ≥ 1220 MPa |
| Pin Body Core Material | Quenched & Tempered Alloy | 40Cr / 42CrMo4 Alloy Structural Steel | Core Hardness: HRC 32–38 |
| Surface Protective Coating | Standard Zinc Finish | Dacromet / Geomet Heavy Barrier | Salt Spray: ≥ 720 h |
| Operating Temperature | -30°C to +120°C | -40°C to +150°C Wide Range | Slurry & Oil Resistant |
| Retaining & Pull Force | Standard Safety Spec | Elastic Retaining Force ≥ 1.8 kN | Anti-Dislodge Tested |
Manufacturing Standards & Quality Control
- Isothermal Heat Treatment: The 60Si2Mn spring retaining clip undergoes computer-controlled isothermal quenching and tempering to prevent permanent plastic deformation during repeated tool swap cycles.
- Dacromet Anti-Corrosion Finish: Coated with a multi-layer Dacromet barrier (>720 hours neutral salt spray resistance per ASTM B117), preventing hydrogen embrittlement and mud-caking seizure.
- 100% Spring Resilience Verification: Every batch undergoes cyclic deflection and spring-back testing to ensure reliable retention under high-torque drilling conditions (>200 kNm).
Maintenance & Refurbishment Installation Guidelines
- Pin Bore Cleaning: Flush the cross-hole of the main joint pin (P/N 259680) with high-pressure water to remove compacted clay and sand before inserting the locking pin (P/N 259681).
- Spring Clip Engagement: Insert the pin body through the main joint pin until the spring retaining clip snaps completely over the collar. Verify that the clip wraps snugly with zero manual wobble.
- Mandatory Retirement Criteria: Inspect the locking pin at every shift. Replace immediately if the spring clip shows micro-cracks, permanent bending, or if manual extraction force falls below nominal levels.
Frequently Asked Questions (FAQ)
Q: Is this locking pin (P/N 259681) 100% compatible with existing Bauer P/N 259680 main connection pins?
A: Yes. The pin diameter, effective insertion length, and spring clip curvature match the exact geometric specifications of original Bauer P/N 259680 pins.
Q: How does Dacromet coating compare to standard electro-galvanizing in bentonite drilling mud?
A: Dacromet provides more than triple the corrosion resistance of standard zinc plating without introducing hydrogen embrittlement into the high-tensile spring steel.
Q: What inspection reports accompany bulk shipments?
A: Each shipment includes an EN 10204 3.1 Material Test Certificate, spring resilience test records, coating thickness verification, and dimensional inspection sheets.
Need Safety Locking Pins for Bauer Rigs (P/N 259681) in Stock?
Contact TSS-TUP engineering sales team today for stock availability, paired main pins (P/N 259680), and rapid global air dispatch.
